3.00 mm
Wafer right angle type
Technical specifications
Current rating : 5 A AC, DC
Voltage rating : 250 Volts AC, DC
Dielectric withstanding voltage : 1500 Volts AC during 1 mn
Operating temperature : -25°C to +80°C
Max processing temperature : 235°C during 5 sec
Insulation resistance : > 1000 MΩ
Contact resistance : < 10 mΩ
Contact : brass
Plating : tin (standard)
Insulator : PBT + 15% GF, UL94V-0
Voltage rating : 250 Volts AC, DC
Dielectric withstanding voltage : 1500 Volts AC during 1 mn
Operating temperature : -25°C to +80°C
Max processing temperature : 235°C during 5 sec
Insulation resistance : > 1000 MΩ
Contact resistance : < 10 mΩ
Contact : brass
Plating : tin (standard)
Insulator : PBT + 15% GF, UL94V-0
C-300-XX-T-PV.jpg)
Create your part number
|
AM1C
Antelec
pin header 1 row right angle or AM2C for pin header 2 rows right angle |
300
Pitch
3.00 mm |
XX
Total
number of contacts |
T
Tin
|
PV
Keyed
with locks |
Product range
Number of pins :
1 row : 2 to 12 pins
2 rows : 2 to 24 pins
1 row : 2 to 12 pins
2 rows : 2 to 24 pins
