2.54 mm
Female header right angle SMT type H = 8.4 mm for pin
0.64 mm
0.64 mm
Technical specifications
Current rating : 3.0 A
Dielectric withstanding voltage : 500 Volts AC during 1 mn
Insulation resistance : > 1000 MΩ
Contact resistance : < 20 mΩ
Operating temperature : -40°C to +105°C
Max processing temperature : 230°C during 30 sec
Contact : brass
Plating : gold or selective
Insulator : nylon-6T, UL94V-0
Dielectric withstanding voltage : 500 Volts AC during 1 mn
Insulation resistance : > 1000 MΩ
Contact resistance : < 20 mΩ
Operating temperature : -40°C to +105°C
Max processing temperature : 230°C during 30 sec
Contact : brass
Plating : gold or selective
Insulator : nylon-6T, UL94V-0
0.64 mm
Create your part number
|
AF1C
Antelec
socket 1 row right angle or AF2C for socket 2 rows right angle |
S
SMT
version |
XX
Total
number of contacts |
G
Gold
(Standard) or T/G for Selective |
In Bulk or
B/A for Reel with pad or T/A for Tube with pad |
Product range
Number of pins :
1 row : 2 to 40 pins
2 rows : 4 to 80 pins
1 row : 2 to 40 pins
2 rows : 4 to 80 pins
176
