RJ 2 ports shielded right angle bottom contact high speed
Technical specifications
Current rating : 1.5 A
Voltage rating : 120 Volts AC
Dielectric withstanding voltage : 1000 Volts AC during 1 mn
Insulation resistance : > 500 MΩ
Contact resistance : < 20 mΩ
Max processing temperature : 235°C during 5 sec
Contact : phosphor bronze
Plating : selective
Insulator : thermoplastic, UL94V-0
Shell : brass nickel plated
Voltage rating : 120 Volts AC
Dielectric withstanding voltage : 1000 Volts AC during 1 mn
Insulation resistance : > 500 MΩ
Contact resistance : < 20 mΩ
Max processing temperature : 235°C during 5 sec
Contact : phosphor bronze
Plating : selective
Insulator : thermoplastic, UL94V-0
Shell : brass nickel plated
.jpg)
Create your part number
|
ARJ
Antelec
RJ |
2
2 ways
|
B
Shielded
|
C
Right
angle version |
HV
High
Speed |
16/16
16 positions
and 16 contacts |
B
Bottom
contacts |
LEDs
colors code (see table page 568) |
560
