RJ 1 to 4 ports plastic straight
Technical specifications
Current rating : 1.5 A
Voltage rating : 120 Volts AC
Dielectric withstanding voltage : 1000 Volts AC during 1 mn
Insulation resistance : > 500 MΩ
Contact resistance : < 20 mΩ
Operating temperature : -55°C to +85°C
Max processing temperature : 235°C during 5 sec
Contact : phosphor bronze
Plating : gold
Insulator : PBT, UL94V-0
Voltage rating : 120 Volts AC
Dielectric withstanding voltage : 1000 Volts AC during 1 mn
Insulation resistance : > 500 MΩ
Contact resistance : < 20 mΩ
Operating temperature : -55°C to +85°C
Max processing temperature : 235°C during 5 sec
Contact : phosphor bronze
Plating : gold
Insulator : PBT, UL94V-0
-P-D-XXXX.jpg)
Create your part number
|
ARJ
Antelec
RJ |
X
Number of
ports (1 or 4) |
P
Plastic
|
D
Straight
|
X/X
Total
number of positions then number of contacts |
540
