2.50 mm
IDC connector SMT type
Technical specifications
Current rating : 1.0 A
Dielectric withstanding voltage : 500 Volts AC during 1 mn
Insulation resistance : > 3000 MΩ
Contact resistance : < 30 mΩ
Operating temperature : -40°C to +105°C
Max processing temperature : 260°C during 5 sec
Contact : phosphor bronze
Plating : tin
Insulator : GF black LCP, UL94V-0
Dielectric withstanding voltage : 500 Volts AC during 1 mn
Insulation resistance : > 3000 MΩ
Contact resistance : < 30 mΩ
Operating temperature : -40°C to +105°C
Max processing temperature : 260°C during 5 sec
Contact : phosphor bronze
Plating : tin
Insulator : GF black LCP, UL94V-0
Create your part number
|
CAD
IDC
|
S
SMT
version |
250
Pitch
2.50 mm |
XX
Total
number of contacts |
T
Tin
|
26/28
Acceptable
gauge AWG 26-28 |
In Bulk or
B/A for Reel with pad |
Product range
Number of contacts :
1 to 10 contacts
1 to 10 contacts
310
