RJ 1 to 4 ports plastic right angle
Technical specifications
Current rating : 1.5 A
Voltage rating : 120 Volts AC
Dielectric withstanding voltage : 1000 Volts AC during 1 mn
Insulation resistance : > 500 MΩ
Contact resistance : < 20 mΩ
Max processing temperature : 235°C during 5 sec
Contact : phosphor bronze
Plating : gold
Insulator : polyester, UL94V-0
Voltage rating : 120 Volts AC
Dielectric withstanding voltage : 1000 Volts AC during 1 mn
Insulation resistance : > 500 MΩ
Contact resistance : < 20 mΩ
Max processing temperature : 235°C during 5 sec
Contact : phosphor bronze
Plating : gold
Insulator : polyester, UL94V-0
-P-C-V2-XXXX-B.jpg)
Create your part number
|
ARJ
Antelec
RJ |
X
Number of
ports (1 or 4) |
P
Plastic
|
C
Right
angle version |
V2
Version 2
|
X/X
Total
number of positions then number of contacts |
B
Bottom
contacts |
