RJ 4 ports shielded right angle version 2
Technical specifications
Current rating : 1.5 A
Voltage rating : 120 Volts AC
Dielectric withstanding voltage : 1000 Volts AC during 1 mn
Insulation resistance : > 500 MΩ
Contact resistance : < 20 mΩ
Operating temperature : -55°C to +85°C
Max processing temperature : 235°C during 5 sec
Contact : phosphor bronze
Plating : gold flash
Insulator : PBT, UL94V-0
Shell : brass nickel plated
Voltage rating : 120 Volts AC
Dielectric withstanding voltage : 1000 Volts AC during 1 mn
Insulation resistance : > 500 MΩ
Contact resistance : < 20 mΩ
Operating temperature : -55°C to +85°C
Max processing temperature : 235°C during 5 sec
Contact : phosphor bronze
Plating : gold flash
Insulator : PBT, UL94V-0
Shell : brass nickel plated
Create your part number
|
ARJ
Antelec
RJ |
4
4 ports
|
B
Shielded
|
C
Right
angle version |
V2
Version 2
|
32/32
32 positions
and 32 contacts |
H
Upper
contacts |
SO
Without
ears |
A
A Type
or B or C (ground features) |
I
With
panel grounds |
554
