USB 3.0 A type female right angle type
Technical specifications
Current rating : 1.8 A (contacts 1 & 4), 0.25 A (other)
Dielectric withstanding voltage : 500 Volts AC during 1 mn
Insulation resistance : > 100 MΩ
Contact resistance : < 30 mΩ
Operating temperature : -25°C to +85°C
Insertion force : < 3.5 Kg
Extraction force : > 1.0 Kg
Contact : brass
Plating : selective gold/tin
Insulator : PBT 30% GF, UL94V-0
Shell : brass nickel plated
Mecanical life : > 5000 cycles
Dielectric withstanding voltage : 500 Volts AC during 1 mn
Insulation resistance : > 100 MΩ
Contact resistance : < 30 mΩ
Operating temperature : -25°C to +85°C
Insertion force : < 3.5 Kg
Extraction force : > 1.0 Kg
Contact : brass
Plating : selective gold/tin
Insulator : PBT 30% GF, UL94V-0
Shell : brass nickel plated
Mecanical life : > 5000 cycles
Create your part number
|
USB
USB
|
9
9 contacts
|
A
A type
|
1
1 port
|
F
Socket
|
C
Right
angle version |
3.0
USB 3.0
|
501
