1.27 mm
Female header SMT type low profile bottom entry for pin
0.40 mm
0.40 mm
Technical specifications
Current rating : 1.0 A
Dielectric withstanding voltage : 500 Volts AC during 1 mn
Insulation resistance : > 1000 MΩ
Contact resistance : < 20 mΩ
Operating temperature : -55°C to +125°C
Max processing temperature : 260°C during 5 sec
Contact : phosphor bronze
Plating : gold flash
Insulator : nylon-6T, UL94V-0
Number of pins :
2 rows : 4 to 100 pins
Dielectric withstanding voltage : 500 Volts AC during 1 mn
Insulation resistance : > 1000 MΩ
Contact resistance : < 20 mΩ
Operating temperature : -55°C to +125°C
Max processing temperature : 260°C during 5 sec
Contact : phosphor bronze
Plating : gold flash
Insulator : nylon-6T, UL94V-0
Number of pins :
2 rows : 4 to 100 pins
Mounting example(s)
0.40 mm
Create your part number
|
AF2D
Antelec
socket 2 rows straight |
B
Bottom
entry |
S
SMT
version |
127
Pitch
1.27 mm |
Empty for
standard version layout or V2 for Version 2 |
XX
Total
number of contacts |
G
Gold
|
H2
Insulator
Height H = 2.0 mm |
Without
Pegs or P for with Pegs |
In Bulk or
B/A for Reel with pad or T/A for Tube with pad |
66
