2.54 mm
IDC socket polarized
Technical specifications
Current rating : 3 A AC, DC
Voltage rating : 250 Volts AC, DC
Dielectric withstanding voltage : 1500 Volts AC during 1 mn
Insulation resistance : > 1000 MΩ
Contact resistance : < 10 mΩ
Operating temperature : -25°C to +80°C
Contact : brass
Plating : tin (standard)
Insulator : nylon-6T, UL94V-2
Assembled wire harness : on request
Voltage rating : 250 Volts AC, DC
Dielectric withstanding voltage : 1500 Volts AC during 1 mn
Insulation resistance : > 1000 MΩ
Contact resistance : < 10 mΩ
Operating temperature : -25°C to +80°C
Contact : brass
Plating : tin (standard)
Insulator : nylon-6T, UL94V-2
Assembled wire harness : on request
 & CFSA-254-XX.jpg)
0.64 mm
Create your part number
|
FSA
Female
IDC single row |
PVL
Keyed
with lock |
XX
Total
number of contacts |
254
Pitch
2.54 mm |
22
Acceptable
gauge AWG 22 or 24, 26 or 28 |
Product range
Number of contacts :
1 row : 2 to 28 contacts
1 row : 2 to 28 contacts
